260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator
260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator
Contact Now

260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator

Minimum Order Quantity : 1 Sets Price : $42,000.00/Sets >=1 Sets
Packaging Details : Sea worthy packing. Supply Ability : 100 Set/Sets per Month
Place of Origin: China Brand Name: Starlight
Certification: ISO Model Number: 260kW

Detail Information
Warranty: 3months-1year Rated Voltage: 400V/600V
Rated Current: 451/344A Speed: 1500/1800RPM
Frequency: 50Hz/60Hz Port: Shanghai/Guangzhou
High Light:

steyr t12 260KW lpg power generator

,

steyr t12 Biogas lpg power generator

,

steyr t12 CBM Gas Electricity Generator

Product Description

Product Overview



260 kW LNG CNG CBM Power Generator


Main Features:



- Highly efficient gas engine
- AC Synchronous alternator
- Gas safety train and gas protection device against leakage
- Exhaust and jacket water ex-changer
- Heating water and jacket water circulation system
- Expansion tank and water jacket heater
- Advanced engine control system, including: ignition system, detonation control system, speed control system, air/fuel ratio control system
-  Strict shop test for all generator sets
- Industrial silencer reduces the noise by 12-20dB (A)
- Unattached switch cabinet and electric control cabinet
- Multi-functional control system with easy operation
- Data communication interfaces integrated into control system
- Lighting and smoke alarm system
- Monitoring battery voltage and charging automatically
- Auto refilling oil system
- Bus interface for connecting to higher level control unit

FACTROY AT A GLANCE

260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator 0

Assembly Workshop

260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator 2

Craftsmanship

260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator 4


Craftsmanship

TECHNICAL SPECIFICATIONS
SN Description Parameter
1 Engine Model BF6M1015C
2 RMP 1500
3 Displacement 11.906L
4 Engine Rated Power 285kW
5 Bore*Stroke 132mm×145mm
6 Pressure Ratio 11.5:1
7 Ignition Sequence 1-6-3-5-2-4
8 Engine Type V-type, 4-Stroke, 4-Valve, Water-cooling
9 Thermostat Opening Temperature 79℃,87℃,Full Opening temperature 94℃,102℃
10 Engine Exhaust Temperature 450-520℃
11 Intake System Turbocharged, intercooled
12 Cooling system Forced Water Cooling
13 Combustion type Lean burn, closed loop control
14 Sparking Mode Electrical controlled single cylinder independent high-energy ignition
15 Lubricating System Pressure splash lubrication
16 Engine Oil Temperature ≤108℃
17 Engine Oil Pressure 70-85psi
18 Engine Oil Consumption ≤0.3g/kWh


Engine Control System

The gas engine is controlled by close-loop lean burn managing system which includes single cylinder independent spark, electric speed regulation system, fuel close loop control system, environment adaptability system, automatic diagnosis and protection system to ensure precise and reliable operation of the engine in all working conditions. The systems satisfy all economical efficiency, power and emission requirements. Furthermore, according to the actual application situation, working conditions and exact fuel compositions, we optimized the whole engine and engine control system for its best performances.

Alternator

Mecc Alte ECO38 AC brushless synchronous alternator and specially designed motion parts are used to endure load shock and interference and ensure the equipment’s long term stability and reliability.

1
Model
 ECO38-2L4/3L4
2 Power Factor 0.8(lag)
3 Generating Efficiency 94.10%
4 Generator Capacity 300kVA/350kVA
5 Phase Three Phase Four Wire
6 Insulation Grade H
7 Protection Grade IP23

Generator Set Control System

DEIF intelligent generator control system is used to achieve automatic start, accelerate, switching in, parallel operation, load automatic allocation, transferring, brake separating, cooling and halt. Remote control system is also available for distance monitor and control.
1 Model DEIF AGC222 Series
2 Functions One button start/stop, Data Display & Recording, Monitoring, Protection
3 Display Rmp/water temperature/running hours/current/ voltage/active power/ wattless power/allocation proportion etc
4 Protection High temperature, low lubricant pressure, over speed, overcurrent, voltage abnormal, short circuit control and alarming



SALES AND SERVICE NETWORK
260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator 6
Successful Projects

 260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator 8


Project in Oil & Gas

260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator 10

Bio-gas Power Generation Project

260KW Natural Gas Biogas LPG Power Generator CBM Gas Electricity Generator 12

Project in Russia
